4mm2 6mm2 10mm2 Pv1-F Custom Solar Panel Cable DC Cable PV Wire For Solar Panel

Price : $0.30-0.35

Packaging Details : Wooden Drum、cardboard box、wooden pallet

Insulation Material : XLPO

Payment Terms : L/C,D/A,D/P,T/T,Western Union

Rated Voltage : 1.5KV

Jacket : PVC

Sheath : XLPO/XLPE

Type : Low Voltage

Rated Current : 55A

Model : PV1-F

Specification : 6mm ²/ 2.5mm ²/ 4mm ²/ 10mm ²/16mm ²/25mm ²/35mm ²

Model Number : PV1-F

MOQ : 1000

Certification : tuv

Conductor Material : Tin Plated Copper

Place of Origin : Shaanxi, China

Supply Ability : 800–1500 kilometers per month

Delivery Time : 30 days

Application : Photovoltaic Power, Construction, Industrial, Power Station, power station/Industrial/photovoltaic power/

Brand Name : F.T

Working temperature : - 40 ℃ - 125 ℃

Contact Now

PV1-F Solar Cable 4mm2 6mm2 10mm2 Custom Solar Panel Cable DC Cable PV Wire For Solar Panel

PV1‑F solar cable stands as the dedicated DC wiring solution tailor‑made for photovoltaic power generation systems, widely applied for connection between solar panels, combiner boxes and inverters. We provide mainstream core sizes of 4mm², 6mm², 10mm², alongside fully customized service including conductor structure, outer diameter, insulation thickness, printing content and packaging scheme, to fit diverse distributed household PV projects, commercial rooftop power stations and large‑scale ground‑mount solar farms.

Manufactured with cross‑linked polyethylene (XLPE) insulation and sheath through electron‑beam cross‑linking process, our PV1‑F cables are engineered for long‑term outdoor exposure. They maintain stable electrical performance and mechanical properties under harsh scenarios such as strong ultraviolet radiation, high‑altitude ozone corrosion, coastal salt fog erosion and extreme temperature fluctuation, delivering reliable power transmission for solar energy systems over a 25‑year service life.

Specifications

Item	Detailed Parameters
Product Model	PV1‑F
Available Cross‑Section	4mm², 6mm², 10mm² (custom sizes supported)
Rated Voltage	DC 1.5kV
Conductor Material	Tinned copper, flexible stranded conductor
Insulation & Sheath Material	Cross‑linked XLPE (electron‑beam cross‑linked)
Operating Temperature Range	-40℃ ~ +120℃
Ampacity (60℃ Ambient)	55A (4mm²), 70A (6mm²), 98A (10mm²)
Conductor Resistance	Strictly complies with TÜV EN 50618 standard
Core Type	Single‑core (double‑core customized available)

Double core solar photovoltaic power cable

Conductor cross‑section(mm²)	Conductor structure(n/mm)	Stranded outer diameter(mm)	Insul. Thick.(mm)	Conductor resistance(Ω/km)	Ampacity 60℃(A)
2*1.2	30/0.25	0.7	5.00*10.30	13.7	30
2*2.5	49/0.25	0.7	5.20*10.80	8.21	41
2*4.0	56/0.285	0.7	5.50*11.20	5.09	55
2*6.0	84/0.285	0.7	6.20*12.60	3.39	70
2*10.0	84/0.40	0.7	7.5*15.20	1.95	98
2*16.0	128/0.40	0.7	9.60*19.70	1.24	132

Single core solar photovoltaic power cable

Conductor cross‑section(mm²)	Conductor structure(n/mm)	Stranded outer diameter(mm)	Insul. Thick.(mm)	Conductor resistance(Ω/km)	Ampacity 60℃(A)
1.5	30/0.25	1.58	4.9	13.3	30
2.5	49/0.25	2.02	5.45	7.98	41
4	56/0.30	2.6	6.1	4.95	55
6	84/0.30	3.42	7.2	3.3	70
10	84/0.40	4.56	9	1.91	98
16	128/0.40	5.6	10.2	1.21	132
25	192/0.40	6.95	12	0.78	176
35	276/0.40	8.74	13.8	0.554	218

4mm2 6mm2 10mm2 Pv1-F Custom Solar Panel Cable DC Cable PV Wire For Solar Panel

Applications of PV1‑F Solar Cable

Residential Distributed PV Systems

Mainly used for DC wiring between solar panels, junction boxes and inverters for home rooftop & balcony solar systems. 4mm² & 6mm² are widely adopted for flexible installation.
Commercial & Industrial Rooftop Solar Power Stations

Suitable for high‑power rooftop PV projects of factories and commercial buildings. 6mm² & 10mm² cables ensure low voltage drop and stable power transmission for large‑capacity solar arrays.
Utility‑Scale Ground‑Mount Solar Farms

Applied in desert, mountain, fishery‑PV and agriculture‑PV complementary power plants. High‑cross‑section cables withstand harsh outdoor environments with UV, ozone, salt fog and extreme temperature for 25‑year service life.
Off‑Grid Solar & Energy Storage Systems

Ideal for island power supply, RV solar systems, solar water pumps and outdoor base stations. Flexible, weather‑resistant cables connect solar modules and energy storage batteries stably.
Special‑Environment PV Projects

Customized for coastal high‑humidity areas, alpine cold regions and desert high‑temperature zones, with excellent anti‑corrosion, anti‑aging and waterproof performance.

Product Advantages

Certified Stable PerformanceComply with TÜV EN 50618, UL4703 and IEC standards. Tinned copper conductor ensures low resistance, low power loss and steady current‑carrying capacity.
Excellent Weather Resistance

Electron‑beam cross‑linked XLPE resists UV, ozone, hydrolysis and salt fog. Operates stably at -40℃~120℃ with 25‑year outdoor service life for harsh‑environment solar projects.
High‑Safety Material

Halogen‑free, low‑smoke and flame‑retardant, meeting IEC 60332‑1‑2, safe for residential, commercial and large‑scale solar stations.
Flexible for Easy Installation

Fine‑stranded tinned copper features great bendability, convenient for narrow‑space wiring and improves project construction efficiency.
Customization & Fast Supply

Support size, length, printing and packaging customization. 4/6/10mm² in stock for bulk orders and urgent delivery.
